IP69K Super Washdown Scales

SWSeries

IP69K

IP68

Withstands extremely damp External
environments Calibration

LED Display

Counting
Function

Comparator
Function

High pressure, high temperature washdown Stainless steel frame and load cell Auto Power
OFF
Ultimate protection against the effects of condensation as well as water*
Streamlined construction for easy cleaning of food-processing residues M
Stainless steel weighing pan, frame and load cell **
Rugged and adjustable (0º, 30º, 60º or 90º) indicator bracket EC Type
Touch sensitive capacitive keys to prevent damage from sharp objects Approval
Auto-tare function to facilitate consecutive check weighing
Three sizes of base units, which are also available separately Software
Pole stand attachable to either the short or long side of the platform
Optional
* Both IP69K and IP68 compliant
** Weighing pan and frame = SUS304 Load cell = SUS630 RS-232C
Interface

Rechargeable
Battery

The display unit as an IP69K indicator (SW-D) NSF
Compliant
You can purchase the SW display unit (SW-D) separately and use it
as an IP69K (as well as IP68) indicator with platforms (load cells)
other than A&D’s.

Model SW-6KS SW-15KS SW-15KM SW-30KM SW-60KM SW-150KM SW-60KL SW-150KL
Capacity
Resolution 6 kg 15 kg 15 kg 30 kg 60 kg 150 kg 60 kg 150 kg
(switchable) 0.005 kg
0.002 kg 0.005 kg 0.002 kg 0.01 kg 0.02 kg 0.05 kg 0.02 kg 0.05 kg
Weighing pan 0.001 kg
0.001 kg 0.002 kg 0.005 kg 0.01 kg 0.02 kg 0.01 kg 0.02 kg

0.0005 kg 0.001 kg 0.002 kg 0.005 kg 0.01 kg 0.005 kg 0.01 kg

250 × 250 mm 300 × 380 mm 390 × 530 mm

❖ g, oz, lb and lb-oz also available (g not available for SW-60K/150K)

Options & Accessories

HC-02i Sealed lead acid rechargeable battery (6 V, 4 Ah) SW-04 RS-422/485 interface SW-10 Long pole stand
SW-11 Desktop/wall-mount stand
SW-03 RS-232C + comparator relay output SW-09 Short pole stand (for SW-6KS/15KS only)

* **SW-03 and SW-04 cannot be used at the same time. SW series is not IP69K compliant with SW-03 or SW-04.

29
