Production Line Weighing Sensors

AD-4212A
AD-4212BSeries

 External
Calibration

 Super Hybrid                                                                                                            AD-4212B
      Sensor
                                                                                                                                          80mm
              AD-4212A
                                                                                                    AD-4212A
  VFD Display
                                                                                        80mm
              AD-4212B
                                        Protection mechanism against vertical and transverse overloading due to actuator
Reverse Backlit                         malfunctions, etc.
        LCD                             Adjustable response characteristics to help cope with the effect of drafts and
                                        vibrations
RS-232C                                 Multiple weighing units*: g, mg, oz, ozt, ct, mom, dwt, gr, (either tl or tol can be
Interface                               added upon request)
                                        Automatic zero display after data output
        GLP                             Wall/panel-mountable display unit
   Compliant                            Possible to create your own weighing pan
                                        Comparator contact output with buzzer (AD-4212A: 3 level / AD-4212B: 3 or 5 level)
         12                             Chemically resistant stainless steel** sensor unit (AD-4212B)
   93                                   Comes with a free calibration weight (OIML Class E2 equivalent)

          6                                                            * A user programmable unit is also available with the AD-4212A series
Clock & Calendar                                                       * * SUS304 for the body and SUS316 for the weighing pan

Memory

 Data Memory
    Function

Counting
with ACAI

Percentage
 Function

                              AD-4212A

 Animal
Weighing

Comparator                              Model            AD-4212A-100 AD-4212A-200                      AD-4212A-600 AD-4212A-1000
  Function                              Capacity
                                        Resolution       110 g               210 g                      610 g              1100 g
 ON                                     Stabilization
                                        time (approx.)*  0.1 mg                                         1 mg
Auto Power
      ON                                Weighing pan      0-30 g: 1.1 sec    0-30 g: 0.8 sec            0-30 g: 0.9 sec  0-30 g: 0.9 sec
                                                         30-110 g: 1.3 sec  30-210 g: 1.0 sec
                                                                                                        30-610 g: 1.1 sec 30-1100 g: 1.1 sec

                              AD-4212A                           50 × 50 mm                                    70 × 70 mm

Auto Power                                               AD-4212B-23        AD-4212B-101                AD-4212B-102     AD-4212B-201 AD-4212B-301
     OFF
                                                                21 g           31 g / 110 g                    110 g
             AD-4212B-101               Model                0.001 mg       0.01 mg / 0.1 mg                 0.01 mg       210 g                   310 g
                                        Capacity
Smart Range                             Resolution             12 sec        4.0 sec / 2.5 sec                4.0 sec              0.1 mg
                                        Stabilization
                                        time (approx.)*                                                                                   2.5 sec

                                        Weighing pan                         ø34 mm                                                50 × 50 mm

Software

                                        * When set to FAST in a good weighing environment

   Optional                             Options & Accessories

               LAN-Ethernet             AD-4212A-01   BCD output / external contact input               AD-4212A-19 Stainless steel breeze break (comes as standard with
                   Interface            AD-4212A-04   5-level comparator contact output (for AD-4212A)                        AD-4212A-100 and all AD-4212B models)
                                        AD-4212A-07   Extension cable (3 m)
22                                      AD-4212A-08   Ethernet interface with WinCT-Plus software       AD-4212A-20 Metal leveling foot

                                                                                                        * Only one of AD-4212A-01, AD-4212A-04, AD-4212A-08, or the standard
                                                                                                            interface can be used.
