Statistical Calculation Function Accumulation (M+) Function
Displays and outputs statistical calculation data including Sums the weighing results and displays the total value
number of data, sum, max, min, range (max – min),
Statistical mean, standard deviation and coefficient of variation Accumulation
Calculation Function
Comparator Comparator Function ON Auto Power ON Function
Function Compares weight values within set limits and makes Activates the weighing mode display automatically
pass/fail judgments Auto Power when plugged in
ON
Auto Power Auto Power OFF Function Underhook Underhook
OFF Turns off the display automatically after a period of Enables magnetic, hot, or contaminated materials to be
inactivity to save power hanged for weighing or for density measurements
Rechargeable Battery Operation Normal Battery Operation
Works with a built-in rechargeable battery unit
Works with off-the-shelf battery cells
Rechargeable
Battery Normal
Battery
Smart Range Smart Range Function Universal Universal Flexi Coms Function
Automatically switches between the precision and Flexi Coms Enables editing of serial data output format or printout
standard ranges, and recovers the full precision range format
with a press of the RE-ZERO (tare) key
M EC Type Approval IP69K Dust and Waterproof
Includes models that are legal for trade in the member Withstands heavy-duty washdown with high-pressure
EC Type countries of the European Union IP69K (8,000 to 10,000 kPa) and high-temperature (80 ± 5 ˚C)
Approval water from up close (100 to 150 mm)
IP68 Dust and Waterproof IP65 Dust and Waterproof
Permits no infiltration of water while immersed to a Permits no infiltration of dust and withstands water
IP68 depth of 1 meter for 24 hours IP65 jetting from any direction
NSF Compliant Software
Meets food protection and sanitation requirements as Data management software available
established by NSF International
NSF Software
Compliant
Abbreviations and Conversion Factors of Weighing Units
Abbreviation Unit Conversion factor (to gram)
g Gram 1g
mg Milligram 0.001 g
kg Kilogram 1000 g
oz Ounce (avoir) 28.349523125 g
lb 453.59237 g
Pound
1 lb = 16 oz
lb-oz Pound-Ounce 1 oz = 28.349523125 g
ozt Troy ounce 31.1034768 g
0.2 g
ct Metric carat 3.75 g
mom Momme 1.55517384 g
0.06479891 g
dwt Pennyweight
37.7994 g
gr Grain (UK) 37.429 g
Tael (HK general, Singapore) 37.5 g
31.25 g
tl Tael (HK jewelry) 11.6638038 g
Tael (Taiwan)
N/A
Tael (China) See below*
tol Tola (India)
SG Specific gravity
N Newton
* Newton = (weight in gram) × (9.80665 m/s2) / 1000
